A photoinitiator is a molecule that creates reactive species (free radicals, cations or anions) when exposed to radiation (UV or visible). They initiate the polymerization process by adding themselves to the monomer or oligomer.

Photoinitiators are used extensively together in combination with cross-linkable monomers and oligomers in ultra-violet-curable inks and coatings, adhesives and many other products.

Photoinitiators can be divided into two classes radical photoinitiators and cationic photoinitiators. Radical photoinitiators can react differently under UV-irradiation. Depending on their reaction they are classified as Norrish Type I or Norrish Type II Photoinitiators.

Norrish Type I-Photoinitiators (Cleavage)

Norrish Type I-Photoinitiators diagram Illustration

Norrish Type I photoinitiators are characterized by a cleavage reaction into two radical fragments of the original photoinitiator. The irradiation with UV-light leads to a homolytic bondage cleavage and generation of two highly reactive radical species. These radicals then initiate the polymerization. The Type I photoinitiator is irreversibly incorporated into the polymer matrix.

Norrish Type II-Photoinitiators (Abstraction)

Norrish Type II-Photoinitiators (Abstraction) Illustration

Norrish Type II photoinitiators, when irradiated by UV-light, need a hydrogen donor to react. Most commonly these hydrogen donors are amines (amine synergists). By UV-irradiation the Type II photoinitiator abstracts a hydrogen atom from the employed synergist forming two radicals. These radicals like the Type I photoinitiators can then initiate the polymerization reaction. Type II photoinitiators normally are not incorporated during the reaction but the synergist is.

Cationic Photoinitiator

Cationic Photoinitiator Illustration

Cationic Photoinitiators react very differently to the previous mentioned Type I/II Photoinitiators. Mainly iodonium and sulfonium salts are employed as cationic photoinitiators. When irradiating these salts with UV-light they undergo, like Type I photoinitiators, homolytic bondage cleavage. The formed radicals react with a proton donor to a Brønsted or Lewis acid. The generated acid then initiates the polymerization.

Ultra-violet curing technology represents an environmentally-friendly and cost-effective alternative to other technologies such as solvent based formulated systems, as there is no water to remove at the end of the printing or coating process, and no solvents to capture or incinerate.

Curing is a set of chemical and physical processes that coating materials must undergo after drying. The coating must attach itself to the substrate physically (adhesion) or chemically (cohesion) and must cohere to itself. It also needs to undergo chemical reactions such as “polymerization” (formation of plastic). These processes are known collectively as curing.

Applications include industrial coatings and coatings for graphic arts. Photoinitiators are used for wood furniture and flooring, plastic, metal and paper, fiber optics, electronic components, automotive components, flexographic inks, screen print inks, lithographic inks, laminating and pressure sensitive adhesives, etc. Photoinitiators are also used in the manufacture of display and touch screens, solar batteries and fuel cells, flexible electronics, medical devices, aerospace and automotive components, lighting components and many more.

UV curable coatings can offer improved performance and visual properties. One of the main advantages from an environmental perspective is the absence of solvents. Further there are energy savings because of faster start-ups and shut-downs – UV lamps turn on and off almost instantaneously. Other advantages of UV-curing include the fact are that they are much faster than thermal processes. UV coatings cure in a matter of seconds, rather than minutes or hours. Productivity is improved as UV coatings cure in a matter of seconds.
